FAP2714 (P/G/W)
Essential IP Phone
4 SIP Accounts
Dual Ethernet Ports
6 Way Conference Call
PoE Support
2.4" Backlit Graphic Display
Equipped with Noise Shield
4 SIP Accounts
2.4" Backlit Graphic Display
PoE Support
Dual Ports
HD Voice
1000 Contacts Phonebook
RJ9 Headset Port
The FIBERME FAP2714 Essential IP Phone is expertly designed to meet the needs of small and medium-sized businesses. This versatile device comes with 4 SIP accounts and features a 2.4-inch screen with a resolution of 132 x 64 pixels, complete with backlighting for easy readability. It offers HD voice quality for crystal-clear communication and supports Power over Ethernet (PoE) for convenient installation. With dual gigabit ports and dual-band WiFi capabilities, the FAP2714 ensures robust and flexible connectivity.
The FAP2714 is not only tailored for business use but is also ideal for hotel room applications, offering customization options to meet the specific needs of both environments. Whether in a bustling office setting or providing top-notch service in a hospitality context, the FIBERME FAP2714 delivers reliable performance and seamless communication.
Main Functions
- Local Phonebook (1000 entries)
- GB Ports (FAP2714G)
- Dual WiFi 2.4GHz / 5 GHz (FAP2714W)
- Call logs (In/Out/Missed, 600 entries)
- Voice Message Waiting Indication (VMWI)
- Call out / Answer / Reject
- Mute / Unmute (Microphone)
- Call Hold / Resume
- Call Waiting
- Intercom
- Caller ID Display
- Speed Dial
- Call Forward (Always/Busy/No Answer)
- Call Transfer (Attended/Unattended)
- Call Parking/Pick-up (Depending on server)
- Redial
- Do-Not-Disturb
- Auto-Answering
- Voice Message (With server)
- 6-party Conference
- Hot Line
- Hot desking
| FAP2714P | FAP2714G | FAP2714W | |
|---|---|---|---|
| SIP Accounts | 4 SIP Accounts | ||
| Display | 2.4” Graphical Display, 132 x 64 Pixels, with Backlit | ||
| Ethernet Ports | Dual100 Mbp Ports, PoE Integrated | Dual Ethernet Gbps Ports, PoE Integrated | Dual100 Mbps Ports |
| WiFi | - | Dual Band WiFi 2.4GHz & 5GHz | |
| Other Ports | 1 x Handset port, 1 x RJ9 Headset port | ||
| Function Keys | 9 Function keys (Hold/Transfer/Voice message/Conference/Phonebook /MWI/Headset/Redial/Hands-free) 4 Soft keys, 4 navigate keys, volume+/- | ||
| Direct IP Call | Supported | ||
| Phonebook | 1000 records; phonebook search/import/export; XML/LDAP remote phonebook; blacklist | ||
| Call History | 600 records; call history: all/missed/dialed/received | ||
| Audio Conferencing | Supports 6-way audio conferencing for easy conference calls | ||
| Network Safety | Physical: Ethernet, dual bridged port for PC bypass IP Mode: IPv4/IPv6 IP Configuration: Static IP / DHCP / PPPoE Network Access Control: 802.1x VPN: L2TP / OpenVPN VLAN LLDP QoS RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035) | ||
| Auto-provision | Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069 | ||
| Audio Codec | Narrowband Codec: G.711a/u, G.723.1, G.726, G.729A/B, iLBC/Opus Wideband Codec: G.722, Opus | ||
| Power | DC: Power Input: 5V/0.6A, Power Consumption(Adapter): 0.8~1.29W, Power Consumption(PoE): 1.25~1.86W | ||
